Assembly steps for Alpha 50 II Road Wheelset
Building a high-performance carbon wheelset is both an art and a science. It requires precision, patience, and an understanding of how individual components work together to create a machine that is not only fast but also reliable.
In this guide, we will take you through the intricate process of building the ICAN Alpha 50 II Disc Wheelset. This wheelset is engineered for excellence, featuring a Toray T700 & T800 carbon fiber construction and a sleek 50mm depth profile. Whether you are a seasoned mechanic or an enthusiastic DIY builder, this walkthrough will provide you with valuable insights into the craftsmanship behind one of our flagship products.
Why Choose the ICAN Alpha 50 II Disc?
Before we dive into the build process, let's explore what makes this wheelset stand out:
Premium Carbon Fiber: Constructed from Toray T700 & T800 carbon fiber, the rim offers an exceptional strength-to-weight ratio and a stunning UD Matt finish.
Optimal Aerodynamics: With an outer width of 28mm and an inner width of 23mm, the 50mm deep rim provides superior aerodynamic performance.
Reliable Components: Equipped with ICAN D21 hubs featuring S&S Ceramic bearings, Pillar SA1423 spokes, and a 2-cross spoke pattern, this wheelset is built for durability and speed.
Versatility: Ready for tubeless setup and compatible with Shimano 11-speed cassettes, it’s perfect for various riding disciplines.
High cost-performance ratio: Compared to wheelsets of the same quality and configuration, the Alpha50 II is priced at less than $500 USD. Shipping and postage are included if purchased from an EU or US warehouse.
Now, let’s get started with the build.
Step 1: Material Display
The foundation of any great wheelset is its components. Before assembly, it’s crucial to inspect each part for any damage or defects.
Rim: The ICAN Alpha 50 II features a unidirectional (UD) matte finish, which not only looks stunning but also ensures even stress distribution.
Hub: The ICAN D21 hub is designed for optimal performance, with S&S Ceramic bearings that reduce friction and increase longevity.
Spokes: Pillar SA1423 spokes are known for their high tensile strength and fatigue resistance.
Nipples: Alloy nipples provide precise tension adjustment and corrosion resistance.
Ensure all components are clean and free from any contaminants that could affect the build quality.
Step 2: Threading the Drive Side Spokes
The drive side of the rear wheel is the most critical area due to the torque applied during pedaling. Proper spoke threading is essential to ensure the wheel's integrity under load.
Insert the spokes into the rim holes, ensuring they are seated correctly.
Begin threading the drive side spokes into the hub flange. Use a spoke wrench to snug them down, but avoid over-tightening at this stage.
Â
Step 3: Tightening the Drive Side Nuts
Once all drive side spokes are threaded, it’s time to apply initial tension.
Use a tensiometer to measure the tension of each spoke. Aim for a consistent tension across all spokes.
Tighten the nuts evenly, working your way around the wheel. This step is crucial for establishing a balanced foundation.
Step 4: Threading the Non-Drive Side Spokes
With the drive side secured, move on to the non-drive side. The goal here is to create a symmetrical spoke pattern that will help distribute stress evenly.
Thread the non-drive side spokes into the hub flange, ensuring they are correctly aligned with the rim holes.
Snug down the spokes using a spoke wrench, maintaining a consistent tension with the drive side.
Â
Step 5: Tightening the Non-Drive Side Nuts
Now, tighten the nuts on the non-drive side, again using a tensiometer to ensure even tension.
Work methodically around the wheel, tightening each nut incrementally.
Pay close attention to the tension differences between the drive and non-drive sides, adjusting as necessary to achieve balance.
Step 6: Initial Adjustment
After the initial tightening, it’s time for a comprehensive check.
Spin the wheel and observe any wobbles or hops. These indicate areas where the spoke tension needs adjustment.
Use a truing stand if available, or a well-lit, flat surface to check for lateral and radial true.
Â
Step 7: Tension Release
As you make adjustments, you may need to release tension from certain spokes to correct misalignments.
Loosen the nuts slightly on spokes that are pulling too tight.
Retighten them once the wheel is closer to true, ensuring the overall tension remains consistent.
Step 8: Secondary Adjustment
The secondary adjustment phase is where precision truly matters.
Fine-tune the spoke tensions to achieve perfect trueness. This may involve multiple iterations of loosening, tightening, and checking.
Focus on both lateral (side-to-side) and radial (up-and-down) alignment.
Step 9: Weighing
The final step in the build process is weighing the wheelset. The rear wheel of the Alpha 50 II wheelset weighs 788g, while a pair weighs 1459 ± 20g. This not only provides valuable data but also gives you a sense of accomplishment.
The ICAN Alpha 50 II Disc Wheelset is designed to be lightweight without compromising on strength. The total weight is optimized for performance, making it an excellent choice for competitive and recreational riders alike.
Conclusion
Building the ICAN Alpha 50 II Disc Wheelset is a meticulous process that showcases the blend of technology and craftsmanship that goes into every ICAN product. By following these steps, you can appreciate the attention to detail required to create a wheelset that performs at the highest level.
Whether you’re upgrading your current setup or building a new bike from scratch, the ICAN Alpha 50 II Disc Wheelset is a reliable and stylish choice. Its combination of premium materials, advanced engineering, and aerodynamic design makes it a standout option for any cyclist.
